These pipe plugs are designed with a safety factor of 4x maximum pressure.
Safety is our first priority!
Product overview
| Ref. Lansas | Description | Max. pressure (bar) | Weight | Length (mm) | |
| B-101-0070 | Pipe plug Lansas Ø 75/150K mm | 2.5 | 1 kg | 200 | |
| B-101-0030 | Pipe plug Lansas Ø 30/60 mm | 2.5 | 0.30 kg | 150 | |
| B-101-0045 | Pipe plug Lansas Ø 45/80 mm | 2.5 | 0.50 kg | 150 | |
| B-101-0065 | Pipe Plug Lansas Ø 65/125 mm | 2.5 | 0.75 kg | 250 | |
| B-101-0075 | Pipe plug Lansas Ø 75/150 mm | 2.5 | 2 kg | 350 | |
| B-101-0100 | Pipe plug Lansas Ø 100/200 mm | 2.5 | 2.5 kg | 350 | |
| B-101-0101 | Pipe plug Lansas Ø 100/200K mm | 2.5 | 1.2 kg | 250 | |
| B-101-0150 | Pipe plug Lansas Ø 150/250 mm | 2.5 | 2.5 kg | 260 | |
| B-101-0151 | Pipe plug Lansas Ø 150/300 mm | 2.5 | 3.3 kg | 470 | |
| B-101-0200 | Pipe plug Lansas Ø 200/400 mm | 2.5 | 5.5 kg | 550 | |
| B-101-0201 | Pipe plug Lansas Ø 200/500 mm | 2.5 | 8 kg | 750 | |
| B-101-0300 | Pipe plug Lansas Ø 300/600 mm | 2.5 | 12 kg | 710 | |
| B-101-0400 | Pipe plug Lansas Ø 400/800 mm | 2.5 | 22 kg | 1150 | |
| B-101-0500 | Pipe plug Lansas Ø 500/1000 mm | 2.5 | 26 kg | 1150 | |
| B-101-0510 | Pipe plug Lansas Ø 500/1400 mm | 1.5 | 55 kg | 2200 | |
| B-101-0600 | Pipe plug Lansas Ø 600/1200 mm | 1.5 | 45 kg | 1400 | |
| B-101-0650 | Pipe plug Lansas Ø 600/1500 mm | 1.5 | 65 kg | 2200 | |
| B-101-0800 | Pipe plug Lansas Ø 800/1600 mm | 1.5 | 80 kg | 2000 | |
| B-101-0850 | Pipe plug Lansas Ø 800/2000 mm | 1.5 | 115 kg | 2750 |
Technische specificaties
Pipe plug Lansas Ø 75/150K mm
B-101-0070Pipe plug suitable for small pipe diameters from 75 upto 150 mm.
-
Article number
B-101-0070 -
Min. diameter
75 -
Max. diameter
150 -
Length (mm)
200 -
Max. pressure (bar)
2.5
Technische specificaties
Pipe plug Lansas Ø 30/60 mm
B-101-0030Pipe plug suitable for small pipe from 30 upto 60 mm.
-
Article number
B-101-0030 -
Min. diameter
30 -
Max. diameter
60 -
Length (mm)
150 -
Max. pressure (bar)
2.5
Technische specificaties
Pipe plug Lansas Ø 45/80 mm
B-101-0045Pipe plug suitable for small pipe from 45 upto 80 mm.
-
Article number
B-101-0045 -
Min. diameter
45 -
Max. diameter
80 -
Length (mm)
150 -
Max. pressure (bar)
2.5
Technische specificaties
Pipe Plug Lansas Ø 65/125 mm
B-101-0065Pipe plug suitable for small pipe diameters from 65 to 125 mm.
-
Article number
B-101-0065 -
Min. diameter
65 -
Max. diameter
125 -
Length (mm)
250 -
Max. pressure (bar)
2.5
Technische specificaties
Pipe plug Lansas Ø 75/150 mm
B-101-0075Pipe plug suitable for small pipe diameters from 75 upto 150 mm.
-
Article number
B-101-0075 -
Min. diameter
75 -
Max. diameter
150 -
Length (mm)
350 -
Max. pressure (bar)
2.5
Technische specificaties
Pipe plug Lansas Ø 100/200 mm
B-101-0100Pipe plug suitable for small pipes of 100 upto 200 mm
-
Article number
B-101-0100 -
Min. diameter
100 -
Max. diameter
200 -
Length (mm)
350 -
Max. pressure (bar)
2.5
Technische specificaties
Pipe plug Lansas Ø 100/200K mm
B-101-0101Pipe plug suitable for pipe diameters from 100 upto 200 mm.
-
Article number
B-101-0101 -
Min. diameter
100 -
Max. diameter
200 -
Length (mm)
250 -
Max. pressure (bar)
2.5
Technische specificaties
Pipe plug Lansas Ø 150/250 mm
B-101-0150Pipe plug suitable for pipe diameters from 150 upto 250 mm.
-
Article number
B-101-0150 -
Min. diameter
150 -
Max. diameter
250 -
Length (mm)
260 -
Max. pressure (bar)
2.5
Technische specificaties
Pipe plug Lansas Ø 150/300 mm
B-101-0151Pipe plug suitable for pipe diameters from 150 upto 300 mm.
-
Article number
B-101-0151 -
Min. diameter
150 -
Max. diameter
300 -
Length (mm)
470 -
Max. pressure (bar)
2.5
Technische specificaties
Pipe plug Lansas Ø 200/400 mm
B-101-0200Pipe plug suitable for pipe diameters from 200 upto 400 mm.
-
Article number
B-101-0200 -
Min. diameter
200 -
Max. diameter
400 -
Length (mm)
550 -
Max. pressure (bar)
2.5
Technische specificaties
Pipe plug Lansas Ø 200/500 mm
B-101-0201Pipe plug suitable for pipe diameters from 200 upto 500 mm.
-
Article number
B-101-0201 -
Min. diameter
200 -
Max. diameter
500 -
Length (mm)
750 -
Max. pressure (bar)
2.5
Technische specificaties
Pipe plug Lansas Ø 300/600 mm
B-101-0300Pipe plug suitable for pipe diameters from 300 upto 600 mm.
-
Article number
B-101-0300 -
Min. diameter
300 -
Max. diameter
600 -
Length (mm)
710 -
Max. pressure (bar)
2.5
Technische specificaties
Pipe plug Lansas Ø 400/800 mm
B-101-0400Pipe plug suitable for pipe diameters from 400 upto 800 mm.
-
Article number
B-101-0400 -
Min. diameter
400 -
Max. diameter
800 -
Length (mm)
1150 -
Max. pressure (bar)
2.5
Technische specificaties
Pipe plug Lansas Ø 500/1000 mm
B-101-0500Pipe plug suitable for pipe diameters from 500 upto 1000 mm.
-
Article number
B-101-0500 -
Min. diameter
500 -
Max. diameter
1000 -
Length (mm)
1150 -
Max. pressure (bar)
2.5
Technische specificaties
Pipe plug Lansas Ø 500/1400 mm
B-101-0510Pipe plug suitable for pipediameter from 500 upto 1400 mm.
-
Article number
B-101-0510 -
Min. diameter
500 -
Max. diameter
1400 -
Length (mm)
2200 -
Max. pressure (bar)
1.5
Technische specificaties
Pipe plug Lansas Ø 600/1200 mm
B-101-0600Pipe plug suitable for pipe diameters from 600 upto 1200 mm.
-
Article number
B-101-0600 -
Min. diameter
600 -
Max. diameter
1200 -
Length (mm)
1400 -
Max. pressure (bar)
1.5
Technische specificaties
Pipe plug Lansas Ø 600/1500 mm
B-101-0650
Pipe plug suitable for pipediameter from 600 upto 1500 mm.
-
Article number
B-101-0650 -
Min. diameter
600 -
Max. diameter
1500 -
Length (mm)
2200 -
Max. pressure (bar)
1.5
Technische specificaties
Pipe plug Lansas Ø 800/1600 mm
B-101-0800
Pipe plug suitable for pipediameter from 800 upto 1600 mm.
-
Article number
B-101-0800 -
Min. diameter
800 -
Max. diameter
1600 -
Length (mm)
2000 -
Max. pressure (bar)
1.5
Technische specificaties
Pipe plug Lansas Ø 800/2000 mm
B-101-0850Pipe plug suitable for pipediameter from 800 upto 2000 mm.
-
Article number
B-101-0850 -
Min. diameter
800 -
Max. diameter
2000 -
Length (mm)
2750 -
Max. pressure (bar)
1.5
